MAGNET SWAN BRIDGE TAP SPARES
Tap Magician compatible replacement tap cartridge to fit Magnet Swan Bridge Lever tap.

For guidance / instructions of how to replace a tap valve step by step please click here

If your tap is dripping or leaking out of the spout then it is time to replace / change the quarter turn ceramic disc cartridges.
Original cartridge known by code PAINI ASME A112.18.1UPC ANSI NSF61 KK G90.

Cartridge has 20 teeth on spline. Hot and cold valves available.
You will require our Anticlockwise open cartridge for the cold side, and clockwise open for the hot side.
If you require both then you can select "Pair".

If your tap is leaking from the neck (where the spout joins the tap body) then the seals inside the spout need replacing.
When you replace the new rubber seals they need greasing with a silicone grease.
The original O'ring kit is known by 3644R / 1506R.

MAGNET SWAN BRIDGE FREQUENTLY ASKED QUESTIONS

How do I remove my Magnet Swan Bridge handle / head?
Remove handle indicator / indice by prising it off. You can then remove the handle retaining screw with a crosshead screwdriver.
Once removed pull the handle away from the tap body and unscrew the handle cover / shroud unscrewing anticlockwise.

How do I replace the tap cartridge?
First make sure you turn the water off. Use 17mm or adjustable spanner to undo cartridge (it will unscrew anticlockwise).
Fit new cartridge (clockwise) and replace the tap handle.

Watch our how to video for further general guidance on removing tap handles and replacing tap cartridges.
